EAM580R-BAE.7LC4.A36A1.A
Blind Hollow Shaft Analog SingleTurn/MultiTurn MAGRES Magnetic Absolute Encoder; With Stator Coupling Dia. 68mm; Bore Dia. 14mm, Clamping Ring on A-Side; Supply Voltage: 14 to 30 Vdc; Interface: 4 to 20 mA; Measuring Range: 0° to 3600°; Output: 1-Channel, rising CW; Connection: 2-Meters prewired Cable, Radial outlet; IP 67
Country of Origin :
Germany
Technical Datasheet:
