2000013.20A
Siba DIN NH gL-gG HRC Fuses with Dual Indicator: 20 Amps, 500 Vac/120 kA, Operating Class: gL/Gg, Size: DIN000/NH00C
2000013.20A
Product Salient Features:
- Class gL-gG DIN NH HRC Fuses
- Confirming to EN/IEC60269-1-2, DIN 43620, DIN VDE 0636 Part 201 / 2011, CE
- All Fuses have Dual blown fuse indicator
Optional
- Available Rated Current: 2, 4, 6, 10, 16, 20, 25, 32, 35, 40, 50, 63, 80, 100 Amps
- Wide range of Fuse-Bases and Accessories available at extra cost
Technical Data
Manufacturer: Siba
Series: 2000013
Fuse Type: NH gL/gG HRC Fuses
Current Rating (A): 20 Amps
Voltage Rating (Vac): 500 Vac
AC Breaking Capacity (kA): 120 kA
Size: DIN000/NH00C
Pre-Arcing I2t Value A2s: 760
Total I2t Value A2s: 1480
Power Loss (W): 1.8 W
Fuse Blown Indicator: Dual
Standards: IEC/EN60269-1-2, DIN 43620, VDE 0636, CE
Packaging Quantity (Pcs.): 3
Weight (Grams): 110
Special Notes
"Please refer above given PDF Data File/s for additional Product Technical & Dimensional information.
We shall not be liable for any technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from the furnishing, performance or use of this material.
The Manufacturer reserves the right to modify technical or dimensional features in the interest of technological advances.
All Trademarks; Logos; Photographs and Product Information are the properties of their respective Owners”.
