GXP8W.A20M110

SingleTurn/MultiTurn Absolute Encoder; Clamping Flange mounting; Solid Shaft Dia. 10h6 x L:20mm; Supply Voltage: 10 to 30 Vdc; Interface: DeviceNet; Absolute Resolution: 13-Bit ST+16-Bit MT; Without Incremental Output; Connection: Flange Connector Radial, M12 5-Pin Male; IP 65

Manufacturer: Baumer IVO
Country of Origin : Germany
Technical Datasheet:
PDF-Icon GXP8W.A20M110
PDF-Icon Datasheet 2
PDF-Icon Datasheet 3
Packaging Quantity: 1
Minimum Order Quantity: 1
Order in Multiples of Quantity: 1
Required Quantity:
Price on Request

Product Salient Features:

  • MultiTurn Absolute Encoder
  • Body Size Dia. 58mm, DUO-LED Status indicator
  • Optical sensing method
  • Permanent check of code continuity
  • High resistance to shock and vibrations
  • Maximum resistance against magnetic fields

Optional

  • Synchro Flange mounting
  • Protection Class: IP 54
Technical Data
Manufacturer : Baumer IVO
Shaft Type : Solid Shaft
Shaft (S)/Bore (B) Dia. : S: 10 mm
Mounting Type : Clamping Flange
Encoder Type : Absolute ST+MT
Sensing Method : Optical
Supply Voltage : 10 to 30 Vdc
Connection Type : Flange Connector Radial - M12 5-Pin
Operating Temperature : From -25 °C to +85 °C
Protection : IP 65
Approval : UL approval / E63076
Weight : 0.35 KG
Special Notes

"Please refer above given PDF Data File for additional Product technical & dimensional information.

We shall not be liable for any technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from the furnishing,performance or use of this material.

The Manufacturer reserves the right to modify technical or dimensional features in the interest of technological advances.

All Trademarks; Logos; Photographs and Product Information are the properties of their respective Owners”.
